GUTE 45mm Dia Steel Bar Bender

Ask Lasest Price
Brand Name :	GUTE
Model Number :	GW55D-4
Certification :	CE,ISO 9001:2000
Price :	1600-1800USD/SET
Payment Terms :	L/C, T/T, D/P, D/A
Supply Ability :	500set/month
Delivery Time :	20 work days

Add to Cart

Product Details
Company Profile

GUTE 45mm Dia Steel Bar Bender

Automatic 45mm diameter Construction Steel Bar Bending Machine

Product Details

Bar bending machine is one kind of steel bar processing machine, widely used construction building field. It consisted by the motor, gear, operation disc, breaker and machine body. This machine is able to bend ribbed steel bar diameter from 6mm to 40/55 mm, with various shapes using in construction project. According to bending capacity, it can be classified GW40,GW50,GW55, model bar bending machine with manual, automatic, PLC.

Features:

1.The motor, 100% copper motor with speed 1420r/min, normally this motor can work 2 years without breaking;
2.The gear, our gear material is ductile iron QT500-7 which have high precision and hardness, promise machine capacity, durability above 5 years.
3.The operation disc material carbon structure steel 45# guarantee the disc long time use with 24 hours;

STEEL BAR BENDER GW55D AUTOMATIC / MANUAL
Bending Capacity	6-45 mm (ob ≤450N/mm2)	6-42 mm (ob ≤650N/mm2)
Operation	Automatic	Manual
Type of Motor	YEJ 112M-4 (Brake motor)	Y 112M-4
HORSE POWER	5.5 HP	5.5 HP
Motor Rotation Speed	1440 R/min	1440 R/min
Speed of Working Disk	8 R/min	8 R/min
Noise Value (1m away)	≤75dB(A)	≤75dB(A)
Weight	595 Kg.	565Kg.
Dimension	910700910 mm	910700910 mm
Certification	2006/42/EC - 2006/95/EC / ISO 9001:2008
